Features and Benefits - Read & Clears Fault code on Heavy and Medium duty trucks - troubleshoot drivability, emission, ABS and body control systems
- Great starter kit for new customers - Easy to use menus and message screens
- The heavy duty standard application provides the functions necessary to diagnose most SAE/TMC J1708/J1587 electronic control system/engine, transmission, brakes, instruments and emissions
- The Multi-Protocol Cartridge (MPC) is an Intel-based Pro-Link® Plus compatible cartridge designed to diagnose today’s J1708, J1939, 160 Baud and ISO 9141 vehicles
- Coupon for 50% off second PCMCIA Card
Includes:
- Pro-Link GRAPHIQ™ scan tool
- Multi-Protocol Cartridge (MPC)
- GRAPHIQ™ Heavy Duty Standard application
- Fault Code Guide
- Data and power cable
- 6-pin J1708 adapter
- 9-pin J1708 adapter
- Manuals
- Storage case
- Coupon for ½ off second PCMCIA Card
FEATURES:
- Display provides 8 lines of information
- Capable of graphing 4 lines of data
- Provides real time diagnostic data
- Easy to use menus and message screens
- Multiple system capability
- Troubleshoot drivability, emission, ABS and body control systems
- Ready to operate in seconds
- Diagnosis for most SAE J1708/1587 electronic engine control, ABS and transmission systems
HEAVY DUTY STANDARD APPLICATION
The heavy duty standard application provides the functions necessary to diagnose most SAE/TMC J1708/J1587 electronic control system/engine, transmission, brakes, instruments and emissions.
MPC
The Multi-Protocol Cartridge (MPC) is an Intel-based Pro-Link® Plus compatible cartridge designed to diagnose today’s J1708, J1939, 160 Baud and ISO 9141 vehicles. It provides a new platform that greatly enhances the flexibility of the Pro-Link® Plus. To address advanced capabilities provided by the manufacturers, the MPC uses PCMCIA cards. The cards are plugged into the back of the unit, and provide additional functions unique to each manufacturer. The following list contains features and functions that are available with this cartridge.
MPC FEATURES
- Custom data list
- Easy application updates via RS-232 port
- Future MPC enhancement by side port
- J1708, J1939, 160 Baud, ISO 9141
- Printer support
- Snapshot feature
PRO-LINK GRAPHIQ™
- HANDHELD DIAGNOSTIC SCAN TOOL FOR ENGINE, TRANSMISSION, ABS AND MORE
- Advanced Functional Tests
- Compatible with Existing Multi-Protocol Cartridge and Standard Pro-Link® Software* which Display 4 Lines of Data as listed below
- Display 8 Lines of Data in Text Mode with Enhanced Pro-Link GRAPHIQTM software as listed below*
- Factory-Level Diagnostic Applications*
- Graph up to 4 Selected Parameters to View Relationships and Trends Over Time
- Large VGA Sunlight Readable Color Display
- OEM Data Parameters
- Proprietary Trouble Codes
- Reprogramming *applications are sold separately
- View and Graph Data Points Simultaneously
SYSTEMS COVERED
- Allison CEC
- Allison World Transmission Electronic Controller (WTEC)
- Bendix ABS
- Caterpillar
- Cummins
- Detroit Diesel
- Eaton Transmission
- Freightliner
- International
- Mack Trucks
- Meritor WABCO ABS
- Non-proprietary OEM data
- Volvo
- ZF Meritor
SUPERSEDES MPS604001C
